When you need low ambient cooling in small server rooms, industrial areas, and even just small residential spaces up to 400 square feet, turn to the MRCOOL Advantage 9,000 BTU Mini Split Heat Pump.
The 3rd generation of MRCOOL's popular Advantage series, this redesigned ductless system features built-in Wi-Fi capabilities allowing you to operate from anywhere with just the touch of your smartphone. Built for year-round use, its multiple operating modes and user-friendly features are designed to deliver the ultimate in comfort.
Efficient Comfort All Year Long
Not only is this MRCOOL 9,000 BTU mini split ultra efficient thanks to its inverter compressor and 18.0 seasonal energy efficiency ratio (SEER), but with multiple operating modes it’ll keep you comfortable all year long. With its cooling, heating, and dehumidification settings, comfort in any season is easy. For even simpler control, turn to its auto setting and the unit will choose the best operating mode based on your set temperature.
Wi-Fi Enabled Comfort
With this 3rd generation, MRCOOL Advantage Mini Split you'll have comfort in the palm of your hand thanks to its Wi-Fi integration.
- MRCOOL Remote App: Download the MRCOOL Remote App (, ), connect your phone to the air conditioner, and control and monitor your room’s comfort with just the press of a finger.
- Operate It With Just Your Voice: Even better, this system is compatible with Amazon Alexa and Google Home.
Low Ambient Cooling
If you want a ductless system that’s able to continue working in even the most extreme environments then you want the MRCOOL A-09-HP-230B. It’s a great choice for server rooms, greenhouses, and other sensitive environments since it can cool in temperatures as low as 5 degrees Fahrenheit.
Additional Features
- Installation Kit Included: Its installation kit includes a 16-foot line set kit.
- Programmable Thermostat: Quickly and easily select and maintain your desired temperature.
- Remote Operation: Use the included remote control to operate the air conditioner from anywhere in your space.
- Sleep Mode: Help conserve energy while you rest with this setting that gradually increases the temperature while you sleep.
- Louver Position Memory: Direct the airflow where you want it to go and the system will remember your preferred settings.
- Multiple Fan Speeds: Its 4 fan speeds ensure you always have the perfect airflow.
- Auto Restart: The unit will automatically resume operation in its previous settings if a power outage occurs.
Keep small rooms up to 400 square, especially server rooms and industrial settings, comfortable all year long with the Wi-Fi enabled MRCOOL A-09-HP-230B Mini Split.
What Customers Love
- Low Ambient Operation: When server rooms and other sensitive areas need cooling in even low temperatures, turn to the MRCOOL Advantage.
- Wi-Fi Integration: Simply download the MRCOOL Remote App to your phone, connect it to your AC, and control this ductless system from anywhere.
Things to Consider
- Professional Installation Required: This ductless system must be installed by a certified HVAC professional.
Specifications
| Number of Zones | 1 |
|---|
| Recommended Coverage Area | 400 sq. ft. |
|---|
| Energy Efficiency Ratio (EER) | 11 |
|---|
| Seasonal Energy Efficiency Ratio (SEER) | 18 |
|---|
| Heating Seasonal Performance Factor (HSPF) | 9.5 |
|---|
| Installation Type | Professional Installation |
|---|
| AHRI Estimated Annual Cooling Cost | |
|---|
| AHRI Estimated Annual Heating Cost | - 230V: $200.00
- 115V: $211.00
|
|---|
| Energy Star | No |
|---|
| Wi-Fi Capable | Yes |
|---|
| Total Cooling Capacity | 9,000 BTUs |
|---|
| Total Heating Capacity | 9,000 BTUs |
|---|
| Automatic Mode | Yes |
|---|
| Fan-Only Mode | Yes |
|---|
| Number of Fan Speeds | 4 |
|---|
| Minimum Operating Temperature - Cooling | 32 degrees F |
|---|
| Maximum Operating Temperature - Cooling | 122 degrees F |
|---|
| Heat Mode | Yes |
|---|
| Minimum Operating Temperature - Heating | 5 degrees F |
|---|
| Maximum Operating Temperature - Heating | 86 degrees F |
|---|
| Dehumidifier Mode | Yes |
|---|
| Compressor Type | Inverter |
|---|
| Outdoor Unit Height | 21.85 in. |
|---|
| Outdoor Unit Width | 30.31 in. |
|---|
| Outdoor Unit Depth | 11.81 in. |
|---|
| Outdoor Unit Weight | 66.8 lbs. |
|---|
| Mounting Type | Wall |
|---|
| Indoor Unit Height | 11.42 in. |
|---|
| Indoor Unit Width | 28.43 in. |
|---|
| Indoor Unit Depth | 7.36 in. |
|---|
| Indoor Unit Weight | 17 lbs. |
|---|
| Maximum Height Difference | 33 ft. |
|---|
| Remote Control | Yes |
|---|
| Programmable Timer | Yes |
|---|
| Auto-Restart | Yes |
|---|
| Refrigerant Type | R-410A |
|---|
| Minimum Indoor Noise Level | 23 dB |
|---|
| Maximum Indoor Noise Level | 36 dB |
|---|
| Refrigerant Connection Type | Flare |
|---|
| Line Length | 16 ft. |
|---|
| Line Set Included | Yes |
|---|
| Liquid Line O.D. | 0.25 in. |
|---|
| Suction Line O.D. | 0.375 in. |
|---|
| Air Filter | Yes |
|---|
| Adjustable Louvers | Yes |
|---|
| Automatic Oscillation | Yes |
|---|
| Voltage | - 230V: 220-240 V
- 115V: 110-120 V
|
|---|
| Factory Precharge | 16 ft. |
|---|
| Color | White |
|---|
