A single outdoor unit and 3 indoor handlers, that’s all the MRCOOL Three Zone Olympus 36,000 BTU Mini Split with Heat Pump needs to keep you comfortable all year long. With a 9k + 9k + 18k design, it’s great for cooling and heating bedrooms and other residential rooms up to 400 square feet. Not only can you control it from just your smartphone but it's efficient too. The system includes 3 indoor air handlers and remote controls, an outdoor condenser, and 25-foot line set kit.
Note: This MRCOOL mini split requires professional installation.
Comfort All Year Long
Unlike some other options, this three-zone mini split isn't just for use in the summer. With multiple operating modes, it's designed for use all year long.
- Cooling: Turn to cool mode and set your desired room temperature between 62 and 90 degrees Fahrenheit.
- Built-In Heat Pump: Heat mode is there to keep your room comfortable all winter long.
- Fan Only Mode: When it’s not quite hot enough to cool or cold enough to heat, you can still have a circulation of fresh air.
Designed to Work in Multiple Room Sizes
One of the top features of this MRCOOL Olympus system is its 3 indoor air handlers. There are two handlers with a 9,000 BTU cooling and heating performance each in rooms up to 450 square feet and an 18,000 BTU unit for even larger spaces. Each unit has a 25-foot line-set connecting it to the outside condenser.
Wi-Fi Enabled Control
Outfitted with the MRCOOL Smart Wi-Fi Kit so you can not only monitor but control this mini split from anywhere with the MRCOOL SmartHVAC App (iTunes, Google Play). With this feature you'll not only have complete remote control of the unit's features but can even control your mini split with just the sound of your voice via Alexa and Google Assistant.
Additional Features
- Maximum Efficiency: With a 22.5 Seasonal Energy Efficiency Ratio (SEER) and 11.5 Energy Efficiency Ratio (EER) it has received an Energy Star rating, so you know it’s designed for maximum efficiency.
- Programmable Thermostat: It’s equipped with a programmable thermostat that maintains your set room temperature.
- Sleep Mode: Available in cool, heat, or auto mode, it saves energy by maintaining a comfortable temperature while you sleep.
- Self Diagnostics: This ductless system is able to detect and alert you to any potential problems such as leaks.
- Timer: Set the air conditioner to automatically turn on or off ahead of time.
- Auto Mode: Depending on your set temperature and your room’s current temperature, the unit will choose the best operating mode for you.
- Adjustable Louvers: Direct the airflow to the areas you want it to go.
- Auto Swing: Let the air conditioner evenly distribute cool or warm air throughout your space.
- Automatic Restart: If a power outage occurs, the unit will resume operation in its previous settings.
Keep three residential spaces comfortable all year long with the powerful yet easy to use MRCOOL Olympus Three Zone Mini Split.
What Customers Love
- Energy Star Rated: Packed with impressive features, it’s able to deliver a powerful yet efficient Energy Star rated performance.
- Three-Zoned Performance: With 2 included air handlers, you’re able to not only cool but heat multiple rooms.
Specifications
| Number of Zones | 3 |
|---|
| Recommended Coverage Area | 1,000 sq. ft., 400 sq. ft., 400 sq. ft. |
|---|
| Energy Efficiency Ratio (EER) | 11.5 |
|---|
| Seasonal Energy Efficiency Ratio (SEER) | 22.5 |
|---|
| California Residents | ⚠ WARNING: This product can expose you to chemicals including lead and lead compounds which are known to the State of California to cause cancer and birth defects or other reproductive harm. |
|---|
| Heating Seasonal Performance Factor (HSPF) | 10.2 |
|---|
| Installation Type | Professional Installation |
|---|
| Wi-Fi Capable | Yes |
|---|
| Total Cooling Capacity | 36000 BTUs |
|---|
| Zone Cooling Capacity | 9000 BTUs |
|---|
| Zone Heating Capacity | 36000 BTUs, 18000 BTUs |
|---|
| Automatic Mode | Yes |
|---|
| Maximum Cubic Feet per Minute (CFM) | 2355 CFM |
|---|
| Fan-Only Mode | Yes |
|---|
| Number of Fan Speeds | 4 |
|---|
| Minimum Operating Temperature - Cooling | 32 degrees F |
|---|
| Maximum Operating Temperature - Cooling | 122 degrees F |
|---|
| Heat Mode | Yes |
|---|
| Minimum Operating Temperature - Heating | 5 degrees F |
|---|
| Maximum Operating Temperature - Heating | 86 degrees F |
|---|
| Dehumidifier Mode | Yes |
|---|
| Compressor Type | Inverter |
|---|
| Outdoor Unit Height | 31.89 in. |
|---|
| Outdoor Unit Width | 37.24 in. |
|---|
| Outdoor Unit Depth | 16.14 in. |
|---|
| Outdoor Unit Weight | 156.5 lbs. |
|---|
| Mounting Type | Wall |
|---|
| Indoor Unit Height | 12.4 in. |
|---|
| Indoor Unit Width | 38.9 in. |
|---|
| Indoor Unit Depth | 8.58 in. |
|---|
| Indoor Unit Weight | 26.9 lbs. |
|---|
| Maximum Height Difference | 32.8 ft. |
|---|
| Remote Control | Yes |
|---|
| Programmable Timer | Yes |
|---|
| Auto-Restart | Yes |
|---|
| Refrigerant Type | R-410A |
|---|
| Refrigerant Connection Type | Flare |
|---|
| Line Length | - 25 ft. Line Set: 25 ft.
- 50 ft. Line Set: 50 ft.
|
|---|
| Line Set Included | Yes |
|---|
| Liquid Line O.D. | 0.25 in. |
|---|
| Suction Line O.D. | 0.50 in. |
|---|
| Air Filter | Yes |
|---|
| Adjustable Louvers | Yes |
|---|
| Automatic Oscillation | Yes |
|---|
| Voltage | 220-240 V |
|---|
| Color | White |
|---|
